iiyama ProLite LH7575UHS-B2AG

Product description

iiyama ProLite LH7575UHS-B2AG

The iiyama LH7575UHS-B2AG is a 75″ 4K digital signage display featuring Android 11, FailOver technology, an SDM slot, and 500 cd/m² brightness. Designed for 24/7 continuous use, it’s ideal for retail, corporate, hospitality, or public environments, offering flexible installation and orientation options.

Video specifications and performance

• Equipped with an IPS panel and matte coating (haze ~25%) for clear, glare-free viewing.
• Delivers native 4K UHD resolution (3840 × 2160) at 60 Hz for ultra-sharp image quality.
• Typical brightness of 500 cd/m² and a static contrast ratio of 1200:1 ensure vivid, well-balanced visuals.
• Response time of 8 ms (GtG) based on iiyama’s official specifications.
• Wide 178° viewing angles both horizontally and vertically for consistent image quality from any position.
• Designed for round-the-clock operation (24/7) with automatic signal switching (FailOver) and cascading support via DisplayPort Out.

Device and software compatibility

The LH7575UHS-B2AG runs on Android 11 and comes with the iiSignage² CMS, allowing direct content management and app installation. It’s compatible with leading digital signage platforms and supports remote network control via LAN or RS-232. Recommended accessories include Intel SDM modules, wall mounts, and cable management systems.

Collaborative and signage features

This display offers a range of professional features including FailOver, iiSignage² content management, and DP-Out cascading. It also supports wireless casting through iiShare and EShare via WiFi or Miracast. With portrait and landscape orientation options, the screen can adapt to any layout. The built-in CMS enables remote content updates and device management with ease.

Technical specifications

• Panel type: IPS, matte (haze ~25%)
• Screen size: 75 inches
• Resolution: 3840 × 2160 (4K UHD) at 60 Hz
• Brightness: 500 cd/m² (typical)
• Contrast ratio: 1200:1 (typical)
• Response time: 8 ms GtG
• Viewing angles: 178° / 178° (horizontal / vertical)
• Connectivity: 3× HDMI, 1× DisplayPort (In), 1× DisplayPort Out, 2× USB (Type A), RJ45 (LAN), microSD, RS-232, IR In/Out
• Audio: 2 × 10 W built-in speakers
• Operating mode: 24/7 continuous operation
• Mounting: VESA 400 × 400 mm
• Power consumption: approx. 127 kWh/1000 h (typical), standby 0.5 W, off 0.3 W
• Weight: approx. 29.5 kg
• Dimensions (W×H×D): 1679.5 × 958.5 × 55 mm
• Certifications: CE, TÜV, RoHS, WEEE, etc.
