Epson TM-T20IV USB/Ethernet Receipt Printer
Internal ref: EPTMTV204 // Manufacturer part #: C31CL47102
80 mm POS thermal printer with a print speed of 250 mm/s, featuring USB, RS-232 and Ethernet connectivity, automatic paper feed adjustment and a built-in paper cutter.
NEW
PC8338 - EU-UK Plug Adaptor
£153.99
£184.79 Incl. VAT
2 years of manufacturer warranty Subject to manufacturer conditions
Pay in 3 interest-free payments of Show more
Key features
- High-speed thermal printing: speeds of up to 250 mm/s to speed up ticket printing
- Triple connectivity: USB 2.0, RS-232 and 10/100 Base-T Ethernet interfaces
- Paper savings: automatic reduction of margins, line spacing and barcode height
- 80 and 58 mm formats: compatible with two roll widths
- Reliability: mechanism rated for 15 million lines and paper cutter rated for 2 million cuts
- Clear printing: 203 x 203 dpi resolution
- Flexible installation: wall mount supplied for easy integration
In the box
- 1 x Epson TM-T20IV printer
- 1 x Mains adapter
- 1 x EURO mains cable
- Paper roll
- 1 x Paper roll spacer
- 1 x Wall mount
- Rubber feet
- 1 x Power button cover
- Documentation
Product range:
Product description
Epson TM-T20IV – Fast POS printing with Ethernet connectivity
The Epson TM-T20IV is a thermal receipt printer designed for professional point-of-sale environments. Its print speed of up to 250 mm/s helps to reduce the time taken to print receipts, whilst its USB, serial and Ethernet connectivity offers a range of options for integration into your POS infrastructure.
Receipts printed at up to 250 mm/s
Direct thermal technology allows printing without ink cartridges or toner. With a maximum speed of 250 mm/s and a resolution of 203 x 203 dpi, the TM-T20IV meets the day-to-day needs of checkout counters where speed and legibility are essential.
It supports rolls with a width of 79.5 ± 0.5 mm or 57.5 ± 0.5 mm, with a maximum diameter of 83 mm. The spacer supplied allows the printer to be adapted to the paper size being used.
USB, RS-232 and Ethernet for versatile integration
This version stands out for its comprehensive connectivity with USB 2.0, RS-232 and 100 Base-TX/10 Base-T Ethernet. This allows you to choose a local connection to your POS system or integrate the printer into a wired network infrastructure.
A connection for opening a cash drawer is also available, making it easy to integrate the printer into a complete checkout system.
Reduce paper consumption
The built-in paper-saving function automatically reduces the top and bottom margins, line spacing and the height of barcodes. The printer can also prepare the top logo for the next receipt before cutting the current one, thereby further reducing the top margin.
This optimisation makes better use of each roll and minimises the consumables required for day-to-day operation at the point of sale.
Designed for professional print volumes
The TM-T20IV is designed for long-term use. Its mechanism has a rated lifespan of 15 million lines and its automatic paper cutter is rated for 2 million cuts.
The print head has a stated service life of 150 km or 150 million pulses. The mean time between failures (MTBF) stated by Epson is 360,000 hours.
Simplified paper handling and installation
The automatic partial-cut paper cutter makes it easier to hand the receipt to the customer. Two sensors detect when the roll is running out and indicate when the paper is nearly depleted, helping staff to plan for replacement.
Measuring 140 x 199 x 146 mm and weighing 1.7 kg, the printer fits easily onto a countertop. The wall mount supplied offers an additional installation option where space is limited.
Use cases and compatibility
The Epson TM-T20IV is suitable for neighbourhood shops, specialist shops, hotels, supermarkets and other point-of-sale outlets. Its USB 2.0, RS-232 and Ethernet interfaces make it easy to integrate into various wired POS systems, whilst its compatibility with 80 and 58 mm rolls allows you to adapt the receipt format to suit your business.
Technical specifications:
| Feature | Value |
|---|---|
| Printing technology | Direct thermal |
| Print speed | 250 mm/s |
| Print resolution | 203 x 203 dpi |
| Colour printing | Black |
| Paper width | 79.5 ± 0.5 mm |
| Paper width | 57.5 ± 0.5 mm |
| Maximum roll diameter | 83 mm |
| Column capacity on 80 mm paper | 48 / 64 |
| Interface | USB 2.0 |
| Interface | RS-232 |
| Network interface | Ethernet 100 Base-TX/10 Base-T |
| Cash drawer connection | Yes |
| Buffer memory | 4 KB or 128 bytes |
| Paper-saving function | Yes |
| Cut type | Partial cut |
| Paper cutter service life | 2,000,000 cuts |
| Mechanism service life | 15,000,000 lines |
| Print head service life | 150 km |
| Print head service life | 150,000,000 pulses |
| Mean time between failures | 360,000 hours |
| End-of-roll sensor | Yes |
| Low paper sensor | Yes |
| Operating voltage | 24 V |
| Standby power consumption | 0.1 A |
| Average power consumption | 1.8 A |
| Operating noise level | 55 dB(A) |
| Operating temperature | 5 °C to 45 °C |
| Operating humidity | 10% to 90% |
| Dimensions | 140 x 199 x 146 mm |
| Weight | 1.7 kg |
Files
Epson TM-T20IV - Datasheet
Product Specs.
| Manufacturer part # | C31CL47102 |
|---|---|
| EAN | 8715946739045 |
| Warranty | 2 years |
| Connectivity | USB-A, Ethernet |
| Corded or cordless | Corded |
