Pack Philips E-Line 86-inch Touchscreen + B-Tech BT8545 Mobile Stand
Internal ref: PH86BDL4252EBTSP // Manufacturer part #: 86BDL4252E/00
A complete solution featuring an 86" Philips E-Line professional touchscreen display and a B-Tech mobile trolley, ideal for collaboration, training and presentations in corporate environments.
Key features
Philips E-Line 86BDL4252E 86-inch touchscreen
- 86" 4K interactive display for collaboration and immersive teaching
- Infrared touch technology with up to 50 simultaneous touch points
- Android 14 with Google EDLA certification: direct access to Google services
B-Tech BT8545 Mobile Stand for Screens up to 86"
- Professional mobile stand for interactive screens and displays from 55" to 86"
- Maximum capacity of 100 kg for touchscreens and digital signage
- VESA compatibility up to 900x600 for professional AV installations
In the box
- 1 x Philips E-Line 86" screen
- 1 x Mains power cable
- 1 x Remote control with AAA batteries
- 1 x 3 m USB-A to USB-B cable
- 2 x Touch pens
- 1 x Documentation
- 1 x B-Tech BT8545 mobile stand
- 1 x AV shelf
- 1 x Mounting kit
- 1 x VESA mounting hardware
- 1 x Brake castors
- 1 x Installation manual
Product description
Philips E-Line 86BDL4252E – 86” 4K interactive display for professional collaboration
The Philips 86BDL4252E/00 is a large-format collaborative display designed for meeting rooms, lecture theatres, educational institutions and co-working spaces. With its 86-inch Ultra HD 4K display, advanced touch technology and Android 14 operating system, it promotes dynamic interactions and real-time collaboration.
Immersive and precise touch experience
0-gap IR touch technology enables smooth and precise writing with up to 50 simultaneous touch points. Palm rejection, stylus recognition and a built-in whiteboard app facilitate collaborative sessions, annotations and interactive brainstorming.
Android environment and Google integration
Thanks to its Google EDLA certification, the display provides direct access to Google services such as Classroom, Docs and Slides. Native integration with Chromebooks and Android devices simplifies content sharing and collaborative use in educational and professional environments.
Designed for intensive use
The anti-glare tempered glass with a hardness rating of 9H effectively protects the screen in high-traffic areas. The blue light filter and ambient light sensor improve user comfort whilst optimising energy consumption.
Wireless sharing and AV integration
With Philips ScreenShare, users can stream content wirelessly from various devices and operating systems. USB-C connections up to 65 W, HDMI 2.0, DisplayPort, OPS and dual Gigabit LAN facilitate integration into professional audiovisual infrastructures.
Professional applications and compatibility
The Philips E-Line 86” is ideally suited to large conference rooms, universities, training centres and collaborative spaces seeking a high-performance large-format interactive display. Compatible with VESA 800 x 600 mm wall mounts and the Philips Wave cloud management platform.
Technical specifications:
| Product type | Interactive collaborative display |
| Screen size | 86 inches |
| Resolution | 3840 x 2160 UHD 4K |
| Brightness | 400 cd/m² |
| Panel technology | ADS |
| Operating system | Android 14 |
| Touch technology | 0-gap infrared touch |
| Touch points | 50 simultaneous points |
| Screen protection | 9H anti-glare tempered glass |
| Audio | 2 x 20 W with built-in microphones |
| Video inputs | HDMI 2.0 x3, USB-C, DisplayPort, VGA |
| USB | USB-C up to 65 W, USB 3.0 x4, USB-B x2 |
| Network connectivity | Dual Gigabit LAN, Wi-Fi 2.4/5/6 GHz, Bluetooth 5.2 |
| RAM | 8 GB |
| Internal storage | 128 GB eMMC |
| Orientation | Landscape 18:7 |
| VESA mount | 800 x 600 mm |
| Dimensions | 1957 x 1170.8 x 97.1 mm |
| Weight | 51.25 kg |
B-Tech BT8545: professional mobile stand for interactive displays and hybrid collaboration
Professional trolley for interactive displays
The B-Tech BT8545 Momentum Edge is a mobile stand designed for professional screens and interactive displays ranging from 55 to 86 inches. Its reinforced structure provides maximum stability during touch use and interactive collaboration in professional environments.
Safe and stable mobility
Equipped with lockable castors with brakes, the BT8545 allows the screen to be moved easily between rooms and workspaces whilst maintaining excellent stability during use. It is ideal for education, corporate settings, hybrid rooms and dynamic collaboration.
VESA compatibility and height adjustment
The stand supports VESA configurations up to 900x600 and allows for multiple height adjustments to adapt the screen to different environments and users. Its hook-on system facilitates quick and secure installation.
Included multifunctional AV shelf
The BT8545 features an AV equipment shelf that can be mounted at the front or rear of the stand. It can also be used as a concealment panel to achieve a cleaner, more professional installation.
Professional use, compatibility and applications
Ideal for interactive touchscreens, hybrid collaboration, education, corporate use, digital signage and video conferencing. Designed for modern AV environments requiring mobility, stability and flexibility.
Technical specifications:
| Product type | Mobile display stand |
| Recommended screen size | 55" to 86" |
| Maximum screen load | 100 kg |
| Maximum shelf load | 5 kg |
| VESA compatibility | Up to 900x600 |
| Installation type | Mobile trolley |
| Castors | Lockable with brakes |
| Height adjustment | 6 positions |
| Shelf adjustment | 3 positions |
| AV shelf included | Yes |
| Installation | Quick hook-on |
| Security system | Lockable screws included |
| Material | Steel |
| Colour | Black |
| Dimensions | 1050 x 1428–1722 x 882 mm |
| Shelf dimensions | 950 x 210 mm |
| Packaging | 100% plastic-free |
| Manufacturer’s reference | BT8545/B |
Files
Philips E-Line 86BDL4252E - Datasheet
BT8545 - Datasheet
Product Specs.
| Manufacturer part # | 86BDL4252E/00 |
|---|---|
| EAN | 8721038101997 |
| Warranty | 3 years |
| By Sector | Education, Corporate and Office |
| Use type | Meeting Room |
| Intended use | Indoor screen |
| Screen type | Flat Screen |
| Screen Technology | LED - LCD |
| Screen Orientation | Horizontal |
| Screen Size | Between 81 and 86 inches |
| Screen Size | 86'' |
| Resolution | 4K |
| Operating hours | 18h per day |
| Brightness | 350 - 700 cd/m² |
| Other Features | Content Sharing, With Android, Remote Control Included |
| VESA standard | 800 × 600 mm |
| Energy efficiency class | F |
| Manufacturer part # | BT8545/B |
|---|---|
| EAN | 5019318309076 |
| Warranty | 10 years |
| By Sector | Retail, Public administrations, Education, Corporate and Office |
| Accessory Type | Support |
| Is Accessory of | Screen |
| Lone worker protection | No |
