Newline STV+ 75'' Commercial Display

Product description

Newline STV+ 75'' Commercial Display

The Newline STV-7524-Plus brings efficiency and clarity together in a 75-inch UHD format. Designed for constant use and powered by Android 14, it’s a practical choice for digital signage, presentations, and environments where screen uptime and sharing are essential.

 Overview of the display

• 75" commercial-grade Direct LED panel
• Narrow bezel, modern industrial design
• Android 14 operating system
• Cast+ for fast screen connection
• Wake-on-LAN and Wake-on-WiFi included
• Compatible with Newline Signage Pro
• Settings managed via Display Management Plus
• Supports use in various public or private settings

Video specifications and performance

Equipped with a 3840 × 2160 UHD resolution and 400 cd/m² brightness, the STV-7524-Plus offers detailed and vivid visuals. It includes a 5000:1 contrast ratio, wide 178º viewing angle, and a fast 6.5 ms response time. The display is engineered for non-stop, 24-hour use, supported by a 60 Hz refresh rate for smooth playback.

Compatibility of devices and software

This screen works with the Click2Cast dongle for quick, wireless screen sharing. It integrates fully with Newline's Cast, Broadcast, Cast+, Signage Pro, and Display Management Plus, tools accessible through the onboard application store.

Collaborative features: how it stands out

With built-in Cast+ and support for Click2Cast hardware, the STV-7524-Plus allows fast, wireless projection from any compatible device. Alongside this, tools like Signage Pro and Display Management Plus offer control over content and usage across multiple displays.

 Technical specifications

• Panel type: Direct LED
• Active display area: 1650 × 928 mm
• Image format: 16:9
• Brightness: 400 cd/m²
• Contrast: 5000:1
• Colours: 1.07 billion
• Viewing angle: 178º
• Response time: 6.5 ms
• Refresh rate: 60 Hz
• Lifetime: 50,000 hours
• Haze level: 2%
• Power (standard): 111 W
• Power (standby): 0.5 W
• CPU: 4 × Cortex-A73 + 4 × Cortex-A53 at 2.20 GHz
• GPU: Arm Mali-G52
• RAM: 4 GB
• Storage: 16 GB
• OS: Android 14
• Wireless: Wi-Fi 5 + Bluetooth 5.0
• VESA mount: 400 × 300 mm
• Ports: 3 × HDMI 2.1, 1 × USB-A 3.0, 1 × USB-A 2.0, LAN (RJ45), AV In, RS232, SPDIF Out, Audio Line Out
• Audio: 2 × 15 W rear-facing speakers
• Operating temperature: 0°C to 40°C
• Storage temperature: -20°C to 60°C
• Humidity range: 10%–90% operating, 20%–80% storage (non-condensing)
