Newline DSX-8626 86" 4K Digital Signage Display
Internal ref: NEWDSX86UK // Manufacturer part #: DSX-8626
A professional 86-inch 4K digital signage display with 700-nit brightness, Android 14 and 24/7 operation for impactful communication in large commercial spaces.
NEW
£1,791.99
£2,150.39 Incl. VAT
2 years of manufacturer warranty Subject to manufacturer conditions
Pay in 3 interest-free payments of Show more
Key features
- 86-inch 4K UHD display designed for large-format digital signage and professional visual communication
- 700-nit brightness ensures excellent visibility in bright commercial environments
- 24/7 continuous operation for reliable performance in demanding installations
- Android 14 operating system with integrated Newline Signage Pro content management
- Portrait and landscape orientation support for flexible deployment options
- Wi-Fi 6, Bluetooth 5.2 and HDMI Out for seamless connectivity and content distribution
- Enterprise management features including LAN, RS232, Wake-on-LAN and Wake-on-WiFi
In the box
- Newline DSX-8626 display
- Remote control
- Power cable
- Wall mounting bracket
- User documentation
Product range:
Product description
Newline DSX-8626 – Large-Format 4K Digital Signage Display for Professional Environments
The Newline DSX-8626 is an 86-inch commercial display engineered for organisations that require impactful digital communication on a large scale. Combining 4K UHD resolution, 700-nit brightness and dependable 24/7 operation, it is designed to deliver clear and engaging content in retail, hospitality, education and corporate environments.
Exceptional Visibility on a Large Scale
The expansive 86-inch screen provides outstanding visibility for promotional content, wayfinding, public information and corporate messaging. With 3840 × 2160 resolution, a 4000:1 contrast ratio and a wide viewing angle, content remains sharp and readable across large spaces.
Android 14 and Centralised Content Management
Powered by Android 14, the DSX-8626 offers a secure and responsive platform for digital signage applications. Integrated support for Newline Signage Pro enables organisations to create, schedule and distribute content efficiently across multiple displays from a central management platform.
Flexible Installation for Diverse Signage Applications
Support for both portrait and landscape orientations allows the display to adapt to a wide range of installation scenarios. From retail advertising and menu boards to reception displays and information screens, the DSX-8626 provides the flexibility required for professional signage deployments.
Advanced Connectivity and Remote Administration
Featuring Wi-Fi 6, Bluetooth 5.2, Gigabit Ethernet, HDMI Out and RS232 connectivity, the display integrates seamlessly into professional AV and IT infrastructures. Additional management tools such as Wake-on-LAN and Wake-on-WiFi simplify remote monitoring and administration across multiple locations.
Ideal Applications and Compatibility
The Newline DSX-8626 is ideal for shopping centres, retail stores, hospitality venues, educational campuses, conference facilities, reception areas and public information displays. Its large format, continuous operation capability and enterprise management features make it an excellent solution for professional digital signage networks.
Technical specifications:
| Screen Size | 86 inches |
| Resolution | 3840 × 2160 (4K UHD) |
| Display Technology | Direct LED |
| Brightness | 700 nits |
| Contrast Ratio | 4000:1 |
| Viewing Angle | 178° / 178° |
| Response Time | 6.5 ms |
| Colour Gamut | 85% NTSC |
| Operating System | Android 14 |
| Processor | Octa-core CPU |
| RAM | 4 GB |
| Storage | 32 GB |
| Wi-Fi | Wi-Fi 6 |
| Bluetooth | Bluetooth 5.2 |
| HDMI Inputs | 2 × HDMI In |
| HDMI Output | 1 × HDMI Out |
| USB-C | 1 × USB-C (15W Full Function Alt Mode) |
| USB Ports | 1 × USB 3.0 |
| LAN | 1 × RJ45 Gigabit Ethernet |
| RS232 | RS232 In and RS232 Out |
| Audio Output | Line Out and S/PDIF Out |
| Speakers | 2 × 15W |
| Screen Orientation | Portrait and Landscape |
| Operation Time | 24/7 |
| VESA Mount | 800 × 600 mm |
| Wake-on-LAN | Yes |
| Wake-on-WiFi | Yes |
Files
Newline DSX Series
Product Specs.
| Manufacturer part # | DSX-8626 |
|---|---|
| EAN | 0850071711318 |
| Warranty | 2 years |
| By Sector | Retail, Hotels and restaurants, Public administrations, Education, Corporate and Office |
| Use type | Digital signage |
| Intended use | Indoor screen |
| Screen type | Flat Screen |
| Screen Technology | LED - LCD |
| Screen Orientation | Horizontal, Vertical |
| Screen Size | 86'' |
| Resolution | 4K |
| Operating hours | 24h per day |
| Brightness | 350 - 700 cd/m² |
| Other Features | With Android, Remote Control Included, Screen |
| VESA standard | 700 x 500 |
