Bose AMM112 Multipurpose Loudspeaker Black

Product description

Bose AMM112 Multipurpose Loudspeaker Black

The Bose AMM112 is a powerful, compact loudspeaker featuring a coaxial two-way design and wide coverage, perfect for live performances, stage monitoring, and installed sound systems, delivering premium clarity, projection, and tonal balance.

Audio specifications

The AMM112 features a 3-inch compression driver and 12-inch low-frequency transducer, delivering peak SPL of 131 dB. Its Beamwidth Matching Waveguide ensures tonal consistency and clarity across the entire coverage area.

Connectivity and Compatibility

Equipped with two Neutrik® NL4 inputs, the AMM112 is compatible with Bose PowerMatch amplifiers and ControlSpace DSPs, as well as Bose AM and AMU loudspeakers, supporting both passive and bi-amp setups.

Design and battery life

Crafted from durable Baltic birch plywood with a black polyurethane finish, the 22 kg cabinet includes ergonomic handles and dual pole cups. Ideal for portable and installed systems; not battery-powered.

Technical specifications

• Frequency response (–3 dB): 70 – 18,000 Hz
• Frequency range (–10 dB): 60 – 20,000 Hz
• Nominal coverage: 110° horizontal × 60° vertical
• Power handling: 300 W (continuous), 2800 W (peak)
• Sensitivity: 96 dB SPL (1 W @ 1 m)
• Max SPL: 131 dB (peak @ 1 m)
• Nominal impedance: 8 Ω (passive)
• Enclosure: Baltic birch, 2-part black polyurethane coating
• Grille: Powder-coated perforated steel
• Mounting: 6 × M10 inserts, 2 × 35 mm pole cups
• Environmental rating: IP43 (FoH use only)
• Dimensions: 457 × 457 × 383 mm
• Net weight: 22.04 kg
