Yealink W90DM

Product description

Yealink W90DM

A scalable and flexible DECT solution

Designed for medium-sized and large enterprises, the Yealink W90DM DECT manager base allows you to cover an entire building, from the lowest to the highest floors, by transmitting radio frequencies to connected base stations (W90B). As a multi-cell system, it automatically switches from one base station to another to ensure uninterrupted connectivity. This means you can stay connected while on the move and access the full company contact directory at all times.

Operating via DECT radio transmission, the Yealink W90DM master base offers an extensive wireless range (between 50 and 300 m), allowing base stations to be installed throughout all premises.

Simplified deployment and flexible installation

With the W90DM, up to 60 W90B base stations can be connected to each master base, enabling businesses to benefit from complete DECT coverage. In addition, mass deployment can be easily carried out via centralised remote configuration of all handsets and DECT base stations using the Yealink DECT Manager portal. This platform also enables maintenance and firmware updates, allowing operations to be centralised and ensuring simplified management of your DECT systems.

Finally, its integrated PoE interface allows professionals to save time and space during installation, as the base can be connected to both the network and power supply using a single cable.

Advanced features for secure communications

This W90DM DECT base, compatible with W53H, W56H, W59R, CP930W and DD (T54W + DD10K) phones, allows the addition of up to 250 handsets, making it ideal for organisations with a large workforce. You can make up to 8 calls per base station and up to 2 simultaneous calls per handset. Finally, the integrated AES encryption protocol in each Yealink W90DM manager base provides enhanced security for communications. This ensures reliable and effective encryption, preventing data from being intercepted or misused.

Technical specifications:

• Multicell IP DECT solution – Manager base
• Synchronisation via DECT and LAN
• Each manager system supports:
  • Up to 60 base stations (W90B)
  • Up to 250 handsets
  • Up to 250 VoIP accounts
  • Up to 250 simultaneous calls
  • Up to 8 calls per base station
  • Up to 2 simultaneous calls per handset
• Caller ID with name and number
• Centralised directory: up to 100 contacts per handset
• Call history: all, incoming, outgoing and missed calls
• Full duplex: natural voice transmission
• Additional features: silent mode, mute, music on hold, message waiting indication
• Hearing aid compatible (HAC)
• Compatible with W53H, W56H, W59R, CP930W and DD phones (T54W + DD10K)
• 3 LED indicators: 1 DECT indicator, 1 role indicator and 1 power/network status indicator (LAN)
• Handset upgrade: OTA (Over-The-Air)
• Range: 50 m indoors and up to 300 m outdoors
• Ports and interfaces: 1 x RJ45 10/100M Ethernet port and 1 x PoE Class 1 port
• Wall-mountable
• Base dimensions: 134 x 100 x 28 mm
